Panamax ITW-MCO4 Analog Station Set and Central Office Line Protector

SKU: ITW-MCO4

$52.60~~$70.00~~

QTY:

Features:

Analog Station Set and Central Office Line Protector
Protects up to 4-wires (2-pairs) per jack. Using RJ11/45 connectors (2in/2out, pins 3, 6, 4, 5 protected)
Auto-Resetting Technology: PTC resistors open when a surge occurs, protecting your equipment, but unlike other fuses, the PTCs close again once the surge passes.
Expandable modular system
Applications: Analog and Central Office lines for PBX or KSU
Agency Approval: UL 497A (Secondary)
Grounding Requirements: Uses Electrical AC Ground
Recommended Grounding Impedance: <0.5Ohm
Signal Perfect Circuitry
Auto-Resetting PTCs: 160 mA (8-10 Ohms)
Clamping Level: 260V
Response Time: 1-5 Nanoseconds
Capacitance: <50pF
Suppression Modes: Metallic and Longitudinal
Wires Protected: 4-wires (2-pairs) per jack (pins 3, 6, 4, 5)
Termination Type: RJ11/45
